Ginger Drying Machine Price

Ginger is generally distributed in subtropical areas, which is rich in a variety of nutrients. Ginger products are very popular in the world, especially in Southeast Asia, which can create a lot of foreign exchange for the country every year. In order to make full use of ginger resources, drying can not only make full use of ginger, but also obtain higher value-added effect. Thus, the drying process of ginger is extremely important. If you want to get into the business of drying ginger, you must own a ginger drying machine. So how much does a ginger drying machine price? Next, I will share the ginger drying machine price for you.

Ginger drying machine price
Now, I will share with you the ginger drying machine price. Ginger drying machine is a customized machine. Different manufacturers have different production technologies and drying levels. The performance, efficiency and configuration of the ginger drying machine produced are different, so the price naturally varies greatly. Generally, the price of the commonly used ginger drying machine is about 3,500-50,000USD, and the price of the mesh belt ginger drying machine is about 30,000-100,000USD. In addition to the basic equipment model, customized processing can also be carried out, and the price needs to be calculated and quoted separately. Next, let us learn the principles, components, advantages and technical parameters of these three ginger drying machines together.

This drying method is to use ginger drying machine to carry out reasonable ginger drying machine. It can not only solve the shortcomings of the traditional method of drying ginger, but also improve the yield and increase the efficiency of drying ginger. At present, heat pump ginger drying machine and mesh belt ginger drying machine are widely used. Let me introduce to you the usage and drying principle of the two machine.

Heat pump ginger drying machine

If we use the ginger drying oven, the equipment is equipped with a small cart with a tray and a tray rack. The heat source of the ginger drying room is air. The heat in the air is absorbed by the heat pump compressor. After compression and release, a large amount of high-temperature hot air can be obtained, so as to realize the continuous and uniform drying and processing of ginger.
One set heat pump ginger drying machine contains: heat pump drying host, drying chamber, fan frame with fan, trolley with tray. The drying chamber is used 100mm polyurethane insulation board, supporting 304 stainless steel trolleys and trays. Put the ginger into the material tray, insert the ginger tray into the material cart and push it into the drying room, and close the sealing door to start drying production. The drying temperature range is 65 ℃ - 85 ℃, and the drying temperature is divided into different temperatures, and the temperature is gradually lowered.

Components of ginger drying machine

One set ginger dryer machine contains: heat pump dehydration host, dryer chamber, fan frame with fan, trolley with tray. The dryer chamber is used 100mm polyurethane insulation board, supporting 304 stainless steel trolleys and trays.

The working principle of heat pump ginger drying room

The heat pump ginger drying machine uses the reverse Carnot principle to let the hot air circulating blower dry the vegatable. Heat Pump ginger machien Compressor Heat Exchanger Blocked Radiator (External to Machine). Compressor and other equipment make up the refrigerant circulation system. The fan impeller rotates, the outside air enters the oven, passes through the heater, forms hot air, and then enters the studio through the gap of the air distribution plate, and a large amount of hot air in the circulating flow continues to enter the new air inlet for supplementation. The moisture discharged after recovery is discharged from the exhaust port. The whole cycle makes the ginger heated evenly and achieves the purpose of drying.

Technical parameters of ginger dryer room

heat pump dryer list
type	machine size(MM)	Capacity (KG)	power	Qty of fan	fan power	total power（kw）	Qty of cart	Qty of tray	cart size(MM)	tray size(MM)
3P A	3500×2200×2200	200-400	2.25	6	0.25/pc	3.75	6	78	670×810	600×800
8P A	5300×2200×2800	450-750	6	12	0.37/pc	10.44	6	156	1210×870	600×800
15P	7500×3000×2800	900-1500	11.25	12	0.55/pc	17.85	12	312	1210×870	600×800
1P D	1180×680×1800	50-80	1	—	—	1	—	15	—	600×800
3P D	2100×930×2100	120-300	3.5	—	—	3.5	—	40/60	—	600×800
8P D	4000×1960×2050	650-1000	8	—	—	8	8	232	600×800	600×800
The drying machine can be equipped according to the user's requirement and the production demands

2. Mesh belt ginger drying machine

If we are using a mesh belt type ginger drying machine, then this equipment has a wide range of heat sources, such as coal heating, gas heating, steam heating, biomass pellet heating, or electric heating. It is a multi-layer continuous drying structure. The gingers are dried and dehydrated layer by layer from top to bottom. The drying speed is fast and the production efficiency is high. It is very suitable for the drying and processing of large quantities of gingers.
One set mesh belt ginger drying machine contains: homogenizer, feeding conveyor,dehydrator host, output conveyor, observation door, heat source, air intake system, control panel. The ginger drying machine consists of 4 parts, namely the feed conveyor, the main machine of the mesh belt ginger drying machine, the heat source and the discharge conveyor. The reformer provides heat, and the through-flow mesh belt ginger drying machine is the main body of the drying equipment, which consists of a cabinet and multi-layer conveyor belts; the electrical control system controls the start, operation and stop of the entire equipment. With the cooperation of other auxiliary components, the drying machien completes the drying and discharging process of food, and realizes the drying process of food drying.

The working principle of mesh belt ginger drying machine

Baixin mesh belt ginger drying machine is a continuous production drying equipment. The main heating methods are electric heating, steam heating and hot air heating. Its main working principle is to distribute the ginger evenly in the network. Through the operation of the machine, the ginger moves in the drying machien, and the hot air extracts the water vapor of the vegetable. So as to achieve the purpose of drying. The working temperature is 40-120 degrees Celsius. The drying cycle is 1-5 hours. Mainly used for agricultural and sideline products such as fruits and vegetables, Chinese herbal medicines, etc. The equipment is easy to operate, saves time, has a healthy drying process, and protects the environment.

Technical parameters of mesh belt ginger drying machine

continuous mesh belt dryer list
Model	operation temperature	drying time	thickness of the material	the size of motor	capacity	heat source	total power
BX-2*6M	40-120℃	0.5-5h	50-200mm	6*2*2.5	200-400kg/h	electricity	66.5kw
						natural gas/propane	12.22kw
						coal/wood chips	13.72kw
						steam	11.22kw
BX-2*9M				9*2*2.5	500-800kg/h	electricity	79.76kw
						natural gas/propane	20.12kw
						coal/wood chips	23.12kw
						steam	16.62kw
BX-2*12M				12*2*2.5	1000-1500kg/h	electricity	153.12kw
						natural gas/propane	33.12kw
						coal/wood chips	36.12kw
						steam	25.62kw

3. All-in-one ginger drying machine

Its drying principle is the same as that of the ginger dryer room. If we use the ginger all-in-one dryer machine, the machine is equipped with a trolley with tray and tray rack. When drying ginger, we put it in a tray, put it on the tray rack of the cart, and then push it into the ginger drying room for drying.
The heat source of ginger all-in-one dryer is air. The heat in the air is absorbed by the heat pump compressor. After compression and release, a large amount of high-temperature hot air can be obtained, so as to realize the continuous and uniform drying and processing of ginger.
The operation of this all-in-one drying equipment is relatively simple, and drying can be carried out only by plugging in the power supply.

Components of ginger all-in-one drying machine

Advantages of ginger all-in-one dryer

1. stainless steel 304 material. The whole machine uses stainless steel material, can work a long time, and keep better heat preservation, bottom have wheeler, can move easily.
2. great energy saving. Heat pump system design, low energy consumption, can save 75% energy than traditional electricity element heating.
3. wide application easy operation. Fit for wide application, seafood, fruit, vegetable, spice, herbs, etc all can use it to dry.
4. gentle drying. Temperature range 40-80°C, low temperature dehydrate processing can better keep material nutrition, during drying, no need to move the machine.

Ginger drying machine price

First of all, the ginger dryer equipment is a customized machine. Different manufacturers have different production technologies and drying levels. The performance, efficiency and configuration of the ginger dryer equipment produced are different, so the price naturally varies greatly.
Generally, the price of the commonly used ginger dryer is about 3,500-50,000USD, and the price of the ginger mesh belt dryer is about 30,000-100,000USD. In addition to the basic equipment model, customized processing can also be carried out, and the price needs to be calculated and quoted separately.


How to choose a suitable ginger drying machine

First of all, it depends on our demand for ginger processing. For large output, use a ginger mesh belt drying machine. Generally, the output of a ginger mesh belt drying machine is 300-2000kg/h. For small output, the output of a heat pump ginger drying machine is 100-5000kg/batch. Oven length and mesh belt layers can be customized. We can choose and match them reasonably according to our own processing requirements.
At the same time, our company also produces ginger production lines. lt includes ginger peeling and head removing machine, ginger washing machine, ginger slicer, air dryer, ginger dryer, ginger grinder ginger powder packaging machine and other equipment. This ginger powder processing line is divided into three parts: pretreatment part drying, part and grinding part. The pretreatment part is dedicated to gingers. The dried and ground parts can be used for other spices, such as garlic, ginger, etc. The processing line adopts advanced technology, high ginger output and direct sales at factory prices. This is the best choice for ginger business and the most ideal eauipment for ginger processinal at present.

Ginger drying process is becoming more and more popular in the world, and ginger drying machine also has bright prospects. Do you want to start a ginger business? If you want to know more professional questions about ginger drying machine, please feel free to contact us online!
