Cassava Equipment

Sep 15, 2022

Cassava Equipment

Cassava is very popular with people, and in some countries, cassava is even a staple food for people. Cassava can be processed into a variety of foods. The most common and convenient way is to dry and flour cassava, which not only prolongs the storage time of cassava, but also increases the added value of cassava. Next, Baixin Machinery will introduce the cassava equipment to you.

First, let's take a look at the processing flow of cassava flour: cassava cleaning and peeling, slicing, drying, grinding, packaging.

According to this processing process, two production equipment can be configured: large-scale cassava flour production equipment and small-scale cassava flour production equipment. Next, we will mainly look at the large-scale cassava flour equipment.

The output of the large-scale production equipment can reach more than 1000kg/h, which is composed of the following equipment: cassava cleaning and peeling equipment, cassava slicer, cassava dryer, cassava grinder, and cassava packing equipment. As shown in the figure below:

Cassava cleaning and peeling equipment: The cassava is placed in the equipment, and the brush sweeps and turns the ingredients for cleaning and removing the skin. Then, it enters the spray water section to wash away the dirt that has been brushed on the raw materials until it is washed. The specially designed screw feeding structure is used to realize fully automatic operation.
Cassava slicing equipment: Cut the cassava into even slices. The thickness of cassava slices is uniform, and the slice thickness can be adjusted as needed. which has a good effect on the later drying process. This uniform cassava slice can keep the time and effect of the drying process under the same conditions, so the overall drying effect will also be very high, which meets the processing standards of large-scale enterprises in the drying of cassava slices.
Multi-layer belt cassava dryer: The dryer is the key equipment, which determines the effect and quality of cassava after processing. Using our mesh belt type cassava dryer, with an intelligent control system, can make cassava drying is always maintained in a reasonable drying environment to ensure the effect of the finished product. The use of this cassava dryer has the advantages of large processing output, high degree of automation, controllable drying effect and quality, and adjustable drying time. Flexible heat source selection: Coal, wood chips, natural gas, diesel, propane, electricity, etc.
Cassava powder making equipment: Grind dried cassava slices to a fineness of 10-120 mesh. The cassava grinder is air-cooled or water-cooled and can work continuously for a long time.
Cassava flour packaging equipment: Generally speaking, cassava powder business requires automatic cassava powder packaging equipment. The cassava powder packaging equipment has a PLC control system, which is intelligent and controllable, and can be quickly adjusted according to customer packaging requirements. Packaging weight and quantity are automatically adjusted.

The above is the large-scale cassava flour processing equipment and the function of each equipment. The only difference between the small-scale cassava flour production equipment and the large-scale production equipment is the energy consumption and output of the equipment. The following are the equipment parameters and reference prices of the two cassava flour production equipment.

1000kg/h Automatic Cassava Flour Processing Equipment and Reference Price:

1000kg/h automatic cassava production equipment
Number Name Power Size Output Price(Dollar)
1 Cassava Cleaning and Peeling Machine 3.75KW 3200*1100*1350mm 1000kg/h 4500
2 Cassava Slicer 1.5KW 900*850*900mm 1000kg/h 3800
3 Cassava Dryer 33.12KW 12000*2000*2500mm 1000kg/h 42000-63000
4 Cassava Grinder 15KW 1200*1000*2000mm 300kg/h 3000
5 Cassava Powder Packing Machine 3.5KW 3000*1500*2600mm 30-60 packs/min 12000
The cassava processing machine can be equipped according to the user's requirement and the production demand. 65300-86300

200-300kg/h Small Output Cassava Flour Processing Equipment

200-300kg/h small output cassava production equipment
Number Name Power Size Output Price(Dollar)
1 Cassava Cleaning and Peeling Machine 0.75KW 2120*840*900mm 500kg/h 1700
2 Cassava Slicer 1.5KW 900*850*900mm 500kg/h 1900
3 Cassava Dryer 3KW 2100*930*2100mm 200-300kg/h 7500
4 Cassava Grinder 5.5KW 750*600*1260mm 150kg/h 2000
5 Cassava Powder Packing Machine 1.6KW 700*750*1650mm 30-60 packs/min 8000
The cassava processing machine can be equipped according to the user's requirement and the production demands. 21100

Cassava Flour Equipment Advantages:

1: Can be customized.
Configure different production equipment according to customer output requirements.
The cassava production equipment is fully automatic and semi-automatic, and customers can choose according to their own needs.
2: Easy to operate.
The cassava production equipment is easy to install and can be used after connecting to the power supply. It is reliable to use and easy to disassemble.
3: Cassava is of high quality.
The dryer adopts medium and low temperature drying. After drying, the original color and nutrients of cassava can be completely retained. The equipment is made of stainless steel, in equipment with food machinery standards.
4:Flexible heat source selection of dryer: Coal, wood chips, natural gas, diesel, propane, electricity etc.
5: Wide range of applications:
Most of the equipment in the equipment are not only suitable for cassava, but also for other fruits and vegetables.

The above are the most common cassava equipment. If you are interested in our cassava equipment, or do not know how to choose the right equipment, please feel free to contact us, we will recommend suitable equipment for you according to your needs.

Cassava Equipment Video
