Vegetable Dewatering Machine

Sep 13, 2022

Vegetable Dewatering Machine

Vegetables play an important role in our daily diet. Eating vegetables regularly can enhance our immunity and resist aging. However, fresh vegetables have a short shelf life, and in rainy weather, the vegetables may rot. Therefore, dehydrated vegetables is not only good for preservation, but also provides more options for cooking methods. Some dried vegetables have entered the market and are deeply loved by people. So what are vegetable dewatering machines? How to choose a suitable vegetable dewatering machine? Now, Baixin Dewatering Company will share with you several vegetable dewatering machines that are energy-saving, environmentally friendly, convenient, and have very good drying color and luster quality.

How to choose a suitable vegetable dewatering machine?

Vegetable dewatering machine are divided into three types: mesh belt vegetable dewatering, vegetable dewatering room and all-in-one vegetable dewatering machine.
In terms of output, the continuous mesh belt vegetable dewatering machine is suitable for manufacturers with large output. Its output is 300-2000kg/h. The output of the vegetable dewatering room machine is smaller than that of the mesh belt vegetable dewatering machine, and the output is 100-5000/batch. The output of the all-in-one vegetable dewatering machine is the smallest, and its output is 100-1500/batch. It is suitable for agricultural plants or small processing plants. Oven length and mesh belt layers can be customized. We can choose and match them reasonably according to our own processing requirements.

1. continuous mesh belt vegetable dewatering machine

Frist of all, let's take a look at the continuous mesh belt vegetable dewatering machine with the largest output. Mesh belt vegetable dewatering machine have a wide range of heat sources such as coal heating, gas heating, steam heating, biomass pellet heating or electric heating. It is a multi-layer continuous drying structure. When drying vegetables, just put the vegetables in the feeding port, and the vegetables will enter the dewatering with the feeding conveyor for drying.
Vegetables are dried and dehydrated layer by layer from top to bottom. The drying speed is fast and the production efficiency is high, which is very suitable for the drying and processing of large quantities of vegetables.

The working principle of continuous mesh belt vegetable dewatering machine

Baixin continuous mesh belt vegetable dewatering machine is a continuous production drying equipment. The main heating methods are electric heating, steam heating and hot air heating. Its main working principle is to distribute the material evenly in the network. Through the operation of the machine, the vegetable moves in the dewatering, and the hot air extracts the water vapor of the vegetable. So as to achieve the purpose of drying. The working temperature is 40-120 degrees Celsius. The drying cycle is 1-5 hours. Mainly used for agricultural and sideline products such as fruits and vegetables, Chinese herbal medicines, etc. The equipment is easy to operate, saves time, has a healthy drying process, and protects the environment.

Components of continuous mesh belt vegetable dewatering machine

One set continuous mesh belt vegetable dewatering machine contains: homogenizer, feeding conveyor,dewatering host, output conveyor, observation door, heat source, air intake system, control panel. The vegetable dewatering consists of 4 parts, namely the feed conveyor, the main machine of the mesh belt vegetable dewatering, the heat source and the discharge conveyor. The reformer provides heat, and the through-flow mesh belt vegetable dewatering is the main body of the drying equipment, which consists of a cabinet and multi-layer conveyor belts; the electrical control system controls the start, operation and stop of the entire equipment. With the cooperation of other auxiliary components, the drying equipment completes the drying and discharging process of food, and realizes the drying process of food drying.

Technical parameters of mesh belt vegetable dewatering machine

continuous mesh belt dehyrdator list
Model operation temperature drying time thickness of the material the size of motor capacity heat source total power
BX-2*6M 40-120℃ 0.5-5h 50-200mm 6*2*2.5 200-400kg/h electricity 66.5kw
natural gas/propane 12.22kw
coal/wood chips 13.72kw
steam 11.22kw
BX-2*9M 9*2*2.5 500-800kg/h electricity 79.76kw
natural gas/propane 20.12kw
coal/wood chips 23.12kw
steam 16.62kw
BX-2*12M 12*2*2.5 1000-1500kg/h electricity 153.12kw
natural gas/propane 33.12kw
coal/wood chips 36.12kw
steam 25.62kw
door in Color steel,baffle in Galvanized,the main frame in Carbon steel.

2. Vegetable dewatering room machine

The second type of dewatering is the vegetable dewatering room.
The vegetable dewatering room machine is equipped with a trolley with trays and tray racks. When we dry the vegetables, we put the vegetables in the tray, on the tray rack of the cart, and push it into the vegetable drying chamber to dry. Vegetables are putted on the shelf car and enter the closed cycle drying room for drying without any pollution in the process. The heat source of the vegetable dewatering room is air. The heat in the air is absorbed by the heat pump compressor. After being compressed and released, a large amount of high-temperature hot air can be obtained, so as to achieve uniform drying and processing of vegetables.

The working principle of vegetable dewatering room machine

The vegetable heat pump dewatering machine uses the reverse Carnot principle to let the hot air circulating blower dry the vegatable. The fan impeller rotates, the outside air enters the oven, passes through the heater, forms hot air, and then enters the studio through the gap of the air distribution plate, and a large amount of hot air in the circulating flow continues to enter the new air inlet for supplementation. The moisture discharged after recovery is discharged from the exhaust port. The whole cycle makes the vegatable heated evenly and achieves the purpose of drying.

Components of vegetable dewatering room machine

One set vegetable dewatering room machine contains: heat pump dewatering host, dewatering chamber, fan frame with fan, trolley with tray. The dewatering chamber is used 100mm polyurethane insulation board, supporting 304 stainless steel trolleys and trays. Put the vegetables into the material tray, insert the material tray into the material cart and push it into the drying room, and close the sealing door to start drying production. The drying temperature range is 65 ℃ - 85 ℃, and the drying temperature is divided into different temperatures, and the temperature is gradually lowered. Generally, the drying time is about 8-10 hours to complete a batch.

Technical parameters of vegetable dewatering room machine

heat pump vegetable dryer list
type machine size(MM) Capacity (KG)  power Qty of fan fan power total powerkw Qty of cart Qty of tray cart size(MM) tray size(MM)
3P A 3500×2200×2200 200-400 2.25 6 0.25/pc 3.75 6 78 670×810 600×800
8P A 5300×2200×2800 450-750 6 12 0.37/pc 10.44 6 156 1210×870 600×800
15P 7500×3000×2800 900-1500 11.25 12 0.55/pc 17.85 12 312 1210×870 600×800
1P D 1180×680×1800 50-80 1 1 15 600×800
3P D 2100×930×2100 120-300 3.5 3.5 40/60 600×800
8P D 4000×1960×2050 650-1000 8 8 8 232 600×800 600×800
The drying machine can be equipped according to the user's requirement and the production demands.

Advantages of vegetable dewatering room machine

1 Wide application. Suitable for vegetable, fruit, seafood, spice etc different kinds of material.
2 High drying capacity. Each hour can drying 3-4kg water.
3 Better drying effect. Can better keep material shape , color , nutrition etc.
4 Simple operating. PLC touch screen control panel , can set up temperature, humidity in advance
5 Low energy consumption. Heat pump system, can save 70% energy.

Other application areas of vegetable dewatering room machine

Heat pumps dewatering machine can be used in many applications, in addition to drying vegetables can also be used in agriculture, industry, seafood, grain, herbal medicine, construction, paper products, condiments, mineral industry, etc.
1. Dried vegetables such as radish, lettuce, pumpkin, carrot, spinach, cassava, etc.
2. Fruits such as apples, lemons, mango slices, dried longan, dried longan, etc.
3. Dried meat such as sausage, beef, duck, ham, etc.
4. Others it can dry noodles/wooden/incense/herbs/floss etc.
Your product is not listed above? We are ready for any new challenge! Contact us for a free product test!

3. All-in-one vegetable dewatering machine

The last vegetable dewatering machine is the all-in-one vegetable dewatering machine with the smallest yield.
The drying principle is the same as that of the vegetable dewatering room machine. The all-in-one vegetable dewatering machine is equipped with a cart with trays and tray racks. When drying vegetables, we put them in trays, put them on the tray racks of the cart, and then push them into the vegetable drying chamber for drying.
The heat source of the vegetable integrated dewatering is air energy. The heat in the air is absorbed by the heat pump compressor. After compression and release, a large amount of high-temperature hot air can be obtained, so as to achieve continuous and uniform drying and processing of vegetables. The operation of this all-in-one drying unit is relatively simple, simply plug in and dry.

Components of all-in-one vegetable dewatering machine

One set all-in-one vegetable dewatering machine contains: power jack, water outlet,exhaust air outlet, supporting wheels, PLC controller pancl, door lock, observation window,circulating air inlet, outlet for hot and dry air, PP tray, stainless steel tray, supporting racks for trys. The vegetable all-in-one machine has compact structure, good energy-saving effect, wide application range, high drying quality, convenient operation, simple installation and disassembly. It is the best drying equipment for small businesses, drying experiments and scientific research. The user only needs to connect the power to use, it is the easiest to operate vegetable dewatering.

Technical parameters of all-in-one vegetable dewatering machine

All-in-one vegetable dryer list
type machine size(MM) Capacity (KG)  power total powerkw Qty of cart Qty of tray cart size(MM) tray size(MM)
1P 1180×680×1800 50-80 1 1 15 600×800
3P 2100×930×2100 120-300 3.5 3.5 40/60 600×800
8P 4000×1960×2050 650-1000 8 8 8 232 600×800 600×800
The drying machine can be equipped according to the user's requirement and the production demands.

Advantages of all-in-one vegetable dewatering machine

1. Stainless steel 304 material. The whole machine uses stainless steel material, can work a long time, and keep better heat preservation, bottom have wheeler, can move easily.
2. Great energy saving. Heat pump system design, low energy consumption, can save 75% energy than traditional electricity element heating.
3. Wide application easy operation. Fit for wide application, seafood, fruit, vegetable, spice, herbs, etc all can use it to dry.
4. Gentle drying. Temperature range 40-80°C, low temperature dehydrate processing can better keep material nutrition, during drying, no need to move the machine.

The above is a brief introduction and technical parameters of the three vegetable dewatering machines of Baixin dewatering machine company. The vegetable dewatering machines produced by our company support customization. If you are interested in our dewatering or want to know more about the vegetable dewatering machine and its price. Please feel free to contact us, and we will get you a satisfactory answer and solution according to your requirements.

Vegetable dewatering machine vedio
